14
RM-WAP-16 RM-WAP-8 Owner’s Manual
General specifications
Network specifications
MAIN SPECIFICATIONS
Dimensions W 171.0 mm × D 172.5 mm × H 43.0 mm
Weight 650 g (including mounting bracket)
Power requirements PoE (IEEE802.3af), 48 V DC
Maximum power consumption 48 V, 0.2 A
In operation
Temperature 0°C – 40°C
Humidity 20% – 85% (no condensation)
Storage
Temperature −20 °C – 60 °C
Humidity 10% – 90% (no condensation)
Indicators
• Power
• Status
•Network port
Maximum device
number with RM-CR
RM-WAP-16 1
RM-WAP-8 2
Accessories
• Mounting bracket : 1
• Owner’s Manual (this document) : 1
Dante/PoE port
• Dante audio/Dante control
• External control
•PoE
• Cable requirements: CAT5e or higher, STP
RM-WAP-16_RM-WAP-8_om_7multi_A0.book 14 ページ ２０２１年２月５日 金曜日 午後３時２８分
