II-26
4-6 Damping Adjustment
Adjustment of Key-Return Damping
Maintenance-mode adjustment of key-return damping is provided on models starting from MarkII PK-CTL
V1.23. PRO models do not include this adjustment (since control continues through key-return movement).
Purpose:
To suppress noise generated when keys begin return during playback, a momentary reverse force is applied
to the key by the solenoid at the start of key return. This is adjusted using the damping adjustment feature
described here.
Operation
Enter maintenance mode: Hold down [ ] and [ ] and switch on the power.
Press [R] 11 times (or 8 times, if model DGT2IIXG or DGT7).
Press [PLAY] to start.
K = Key number
D = Damping value
t = Tempo
v = Velocity
Check: Key return movement
Adjust: Damping value (0 to 16)
Use [+/YES] [–/No] to change the value.
Low values: Key returns quickly.
High values: Key jerks back downward during return.
Tempo (t): Use [→] [←] to adjust.
Volume (v): Adjust using normal volume control
*** KEYBOARD ***
*** Damp Adj ***
Damp t100 v001
K=XX D=XX
Default GP 14
S4 10
UP 6
DGT211XG 14
5 with insulating sponge From 97/12 #019670
0 From PK-CTL V1.13 From 98/5 #021004
To Next Page
