Yamaha SR-C20A Quick Start Guide

En 5
Remove the battery insulating strip before attempting to use the
remote control.
 NOTE
A Lithium battery (CR2025) has already been inserted into the remote
control.
Operating range of the remote control
Use the remote control within the range shown in the following
illustration:
Installed on a TV stand
Wall-mounted
Preparing the remote control
Battery insulating strip
Within 6 m (20 ft)
Remote control
sensor
Installing the sound bar
Refer to the User Guide. When installation
and all connections are complete, power off
sound bar and hold down BASS EXT on the
sound bar's remote control for at least five
seconds. The frequency characteristics are
configured for wall mount installation.
Controls
Controls
User Guide

Yamaha SR-C20A Specifications

General

Product color	White
TV stand usage	-
Construction type	Assembly kit
Smartphone remote support	Yes
Audio decoders	Dolby Digital, Dolby Pro Logic II
RMS rated power	100 W
Audio output channels	- channels
Tweeter impedance	6 Ω
Soundbar speaker RMS power	40 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	13 W
Cables included	AC, Optical
Subwoofer location	Built-in
Subwoofer frequency range	65 - 230 Hz
Wi-Fi	No
Bluetooth version	5.0
Connectivity technology	Wired & Wireless
Digital audio optical in	2

Weight and Dimensions

Depth	94 mm
Width	600 mm
Height	64 mm
Soundbar weight	1800 g
