Part 2 : Removing the old strings
1 Loosen the locking lever of the FC (FingerClamp) nut. (Fig. )
2 Pull up the locking levers of the FC tremolo. (Fig. )
3 Loosen the tuning machines to remove the old strings from the
tuning machines in the standard manner. (Fig. )
4 Remove the old strings from the body back. (Fig. )
* It is not needed to detach the back cover to remove the
strings.
Locking Lever
English
Locking Lever
Loosen
Loosen the locking nut
Pull up the locking lever
Remove old strings
Pull off old strings
* The “Tremolo Unit Holder” prevents the tremolo unit from
sinking into the tremolo cavity.
* If the tremolo arm slides away from the arm base, tighten
the screw on the side of the arm base. (Fig. )
