Welcome to the big time
THRC212/112
THRC212/THRC112
Stack the odds in your favor
Almost all of the classic tube sounds of the last few decades have been a product of the synergy between a
high-quality amp head and a dedicated speaker cabinet designed to complement the unique sonic character-
istics of the amp. The THRC112/THRC212 are no different, and have been crafted and tuned specifically to
accommodate the versatile amp, speaker, and valve simulations of THR amp heads. The compatibility doesn’t
stop there; the THRC112 is a 1x12” cabinet that has been optimized for use with the THR100H, while the
THRC212 features two 12” speakers in a left-right configuration as is compatible with stereo inputs, so you
can take full advantage of the THR100H Dual’s unique dual amp functionality to give you the sound of two
distinctive speakers at once. Even the exterior of the enclosures has been matched to the classic design of the
THR amp heads. The THRC112 and THRC212 make it easier than ever to dial in the legendary tube sounds
you’ve always dreamed of, or cut loose with your own trademark tone that will increase your odds of winning
over any audience.
THR100H Dual, THR100H Specifications
THR100H Dual, THR100H Specications
THR100H Dual THR100H
Amp Type SOLID, CLEAN, CRUNCH, LEAD, MODERN SOLID, CLEAN, CRUNCH, LEAD, MODERN
Tube Type EL34, 6L6GC, KT88, EL84, 6V6 EL34, 6L6GC, KT88, EL84, 6V6
Effects BOOSTER (*White/Amber/Green)
REVERB (*Hall/Room/Plate/Spring)
NOISE GATE (*OFF/1/2/3)
FX LOOP (*PARALLEL/SERIAL)
SPEAKER SIMULATION
(*Impulse Response)
*Only selectable in the THR HD_H Utility
BOOSTER (*White/Amber/Green)
REVERB (*Hall/Room/Plate/Spring)
NOISE GATE (*OFF/1/2/3)
FX LOOP (*PARALLEL/SERIAL)
SPEAKER SIMULATION
(*Impulse Response)
*Only selectable in the THR HD_H Utility
Control SW Front POWER, AMP SELECT, BOOSTER x2 POWER, BOOSTER
Control Knob
Front
AMP I AMP TYPE, BOOSTER, GAIN, MASTER,
BASS, MIDDLE, TREBLE, PRESENCE
REVERB, LEVEL
AMP TYPE, BOOSTER, GAIN, MASTER,
BASS, MIDDLE, TREBLE , PRESENCE,
REVERB, LEVEL
AMP II AMP TYPE, BOOSTER, GAIN, MASTER,
BASS, MIDDLE, TREBLE, PRESENCE,
REVERB, LEVEL
N/A
Control SW Rear CLASS A/AB x2
GND LIFT
IMPEDANCE 4/8/16Ω
POWER OUTPUT 25/50/100W
CLASS A/AB
GND LIFT
IMPEDANCE 4/8/16Ω
POWER OUTPUT 25/50/100W
Control Knob Rear TUBE TYPE SELECT x2 TUBE TYPE SELECT
Input/Output Front INPUT I (1/4” Phone)
INPUT II (1/4” Phone)
INPUT (1/4” Phone)
Input/Output Rear PHONES (1/8” Mini Stereo)
FOOTSWITCH (5pin DIN)
EFFECT LOOP SEND/RETURN
(Stereo 1/4” Phone)
SPEAKER OUT 1 (1/4” Phone),
SPEAKER OUT 2 (1/4” Phone)
LINE OUT I (XLR), LINE OUT II (XLR)
AC IN Jack
PHONES (1/8” Mini Stereo)
FOOTSWITCH (5pin DIN)
EFFECT LOOP SEND/RETURN
(1/4” Phone)
SPEAKER OUT (1/4” Phone)
LINE OUT (XLR)
AC IN Jack
USB (TO HOST)
l l
Power Amplifier Type ClassD ClassD
Rated Power Output Single Amp: 100W (8/16Ω) 50W (4Ω)
Dual Amp: 100W (50W+50W)
100W (8/16Ω)
50W (4Ω)
A/D Resolution 24 bit + 3 bit floating 24 bit + 3 bit floating
Sampling Rate 44.1 KHz 44.1 KHz
D/A Resolution 24 bit 24 bit
Sampling Rate 44.1 KHz 44.1 KHz
Input Level INPUT -10 dBu/ 1 MΩ -10 dBu/ 1 MΩ
RETURN 0 dBu/ 10KΩ 0 dBu/ 10KΩ
Output Level PHONES 10 mW/ 30 Ω 10 mW/ 30 Ω
SEND 0 dBu/ 10 KΩ 0 dBu/ 10 KΩ
LINE OUT +4 dBu/ 600Ω +4 dBu/ 600Ω
Power Consumption 60W 40W
Power Voltage 100 - 240V 100 - 240V
Frequency 50/60 Hz 50/60 Hz
PC Interface Type USB 2.0 USB 2.0
Body Dimensions W445 x D248 x H125 mm W445 x D248 x H95 mm
Weight 4.2 kg 3.6 kg
Accessories AC Cable, User Manual, Footswitch,
Footswitch Cable
AC Cable, User Manual, Footswitch
Footswitch Cable
FSW2
Bundled Footswitch for
THR100H Dual
FSW1
Bundled Footswitch for
THR100H
Connection 5pin DIN 5pin DIN
Control SW AMP I/II, AMP I+II, BOOSTER,
REVERB, FX LOOP
BOOSTER, REVERB,
FX LOOP
Body Dimensions W370 x D60 x H53 mm W370 x D60 x H53 mm
Weight 0.8 kg 0.8 kg
THRC212, THRC112 Specifications
THRC212 THRC112
Type
Closed Back Closed Back
Speakers Size
2x12” 1x12”
Name
Left: Eminence Legend1218
Right: Eminence The Tonker
Eminence Legend1218
Frequency
70Hz-5.5kHz 70Hz-5.5kHz
Power Rating
150W+150W or 300W (150W+150W) 150W
Impedance
8Ω or 16Ω (8Ω+8Ω) 8Ω
Input Rear
INPUT （(1/4”（Phone) x3 INPUT (1/4”（Phone)
Control SW Rear
INPUT SINGLE/DUAL N/A
Body Dimensions
W701 x H471 x D301 mm W481 x H371 x D271 mm
Weight
24kg 13kg
Material
Plywood 18mm Plywood 18mm
Accessories
User manual User manual
THRC212 THRC112
THRC212
Specially designed to be the perfect companion to THR100H Dual,
the THRC212 features mismatched Eminence Legend1218 and The
Tonker 12” drivers to provide the perfect balance of clarity, punch
and vintage warmth. With switchable mono or stereo operation, you
can choose which driver to partner with which amp for another level
of tone customization.
TH RC112
The compact THRC112 features a single
Eminence Legend1218 12” driver for pow-
erful, punchy tone from a lightweight and
ultra-portable enclosure.
15
16

Yamaha THR10C Specifications

General

Amplifier class	-
RMS rated power	10 W
Number of speakers	2
Audio output channels	2.0 channels
Peak power per channel	5 W
Battery type	AA
Power source type	AC, Battery
Audio (L/R) in	1
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Power cord included	Yes
Suitable for	Electric guitar
Product color	Black

Weight and Dimensions

Depth	120 mm
Width	271 mm
Height	167 mm
Weight	2800 g
