Yamaha WOLVERINE RMAX2 2024 User Manual

7-6
7
EBU39151
On-Command drive knob
The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF. LOCK”).
For example, the vehicle requires more effort to turn in “DIFF. LOCK” than in “2WD”. Always stop
the vehicle before changing the position of the On-Command drive knob. The meter display
changes according to the selected drive mode. The drive train icon, and the differential gear lock
indicator light come on as follows:
Knob position Indication Drive mode
“2WD” (two-wheel drive): Power is supplied to the rear
wheels.
“4WD” (four-wheel drive): Power is supplied to the rear and
front wheels.
“DIFF. LOCK” (four-wheel drive with the differential gear
locked): Power is supplied to the rear and front wheels and
the differential gear is locked.
Unlike in four-wheel drive, all wheels turn at the same
speed.
UD2670E0.book Page 6 Tuesday, April 25, 2023 1:24 PM

Yamaha WOLVERINE RMAX2 2024 Specifications

General

Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Engine Displacement	999cc
Final Drive	Shaft
Front Brakes	Dual hydraulic disc
Fuel System	Fuel Injection
Ignition	TCI
Front Suspension	Independent double wishbone
Rear Suspension	Independent double wishbone
Rear Brakes	Hydraulic disc
Bed Capacity	600 lb
Towing Capacity	2, 000 lbs
