9-24
9
ECB03590
When checking or changing the final gear
oil, make sure that no foreign material en-
ters the final gear case. If necessary, clean
the final gear oil filler bolt and surrounding
area.
Checking the final gear oil level
1. Park the vehicle on a level surface.
2. Remove the final gear oil filler bolt and its
gasket, and then check the oil level in the
final gear case. The oil level should be at
the brim of the filler hole.
3. If the oil is below the brim of the filler hole,
add sufficient oil of the recommended
type to raise it to the correct level.
4. Check the gasket for damage, and re-
place it if necessary.
5. Install the oil filler bolt and its gasket, and
then tighten the bolt to the specified
torque.
Recommended oil:
YAMALUBE
SAE 80W-90 API GL-5 Hypoid gear oil
Oil quantity:
0.40 L (0.42 US qt, 0.35 Imp.qt)
1. Final gear oil filler bolt
2. Gasket
3. Final gear oil
4. Correct oil level
