Tire inspection
When the tire tread depth has worn to 3 mm
(0.12 in) replace the tire. If the tire has a nail or
glass fragments in it, or if the sidewall is
cracked, replace the tire.
OPERATING TIRE PRESSURE (cold):
VEHICLE LOAD of 0.0–200.0 kg (0–441 lb)
FRONT: (Recommended)
110.0 kPa (1.100 kgf/cm², 16.0 psi)
REAR: (Recommended)
110.0 kPa (1.100 kgf/cm², 16.0 psi)
Front: (Minimum)
103.0 kPa (1.030 kgf/cm², 15.0 psi)
Rear: (Minimum)
103.0 kPa (1.030 kgf/cm², 15.0 psi)
VEHICLE LOAD of 200.0–510.0 kg (441–
1124 lb)
FRONT: (Recommended)
117.0 kPa (1.170 kgf/cm², 17.0 psi)
REAR: (Recommended)
200.0 kPa (2.000 kgf/cm², 29.0 psi)
Front: (Minimum)
110.0 kPa (1.100 kgf/cm², 16.0 psi)
Rear: (Minimum)
193.0 kPa (1.930 kgf/cm², 28.0 psi)
Vehicle load is total weight of operator, pas-
sengers, accessories, cargo, and trailer
tongue weight. Do not exceed maximum
vehicle load of 510.0 kg (1124 lb).
1. Tire tread depth
