9-14
9
6. Remove the engine oil tank drain bolt and
its gasket to drain the engine oil from the
oil tank. (Use a trough or a similar object
as shown to prevent oil from spilling on
the frame.)
1. Engine oil tank filler cap
2. Cylinder head cap
1
2
1. Engine oil tank drain bolt
2. Gasket
1. Trough
2
1
1
