B4J-F151J-00
MAX 7.3 INCH
(185MM)
WARNING
Improper Use of Off-Highway Vehicle Can Cause Severe Injury or Death
Be Prepared
Fasten seat belts.
Wear an approved
helmet, eye protection
and protective gear.
Passengers must be able
to reach the handhold while
keeping feet flat on floor and sitting
upright with back against seat.
Stay completely inside the vehicle.
Pay Attention and Plan Ahead
If you think or feel the vehicle
may tip or roll, reduce your
risk to injury:
Keep a firm grip on the
handhold and brace yourself.
Do not put any part of
your body outside of the
vehicle for any reason.
Do not hold cage or door.
B4J-F17A9-00
•
•
•
•
•
•
•
B4J-F1684-00
INTAKE MANIFOLD
#1
PRESS. SENSOR
THROTTLE BODY
SOLENOID VALVE
#1
#2
ROLL
OVER
VALVE
CANISTER
TO ATMOSPHERE
FROM FUEL TANK
VACUUM HOSE ROUTING
EMISSION HOSE ROUTING
12
13
11
