Tire inspection
When the tire tread depth has worn to 3 mm
(0.12 in) replace the tire. If the tire has a nail or
glass fragments in it, or if the sidewall is
cracked, replace the tire.
OPERATING TIRE PRESSURE (cold):
VEHICLE LOAD of 0.0–200.0 kg (0–441 lb)
FRONT: (Recommended)
83.0 kPa (0.830 kgf/cm², 12.0 psi)
REAR: (Recommended)
97.0 kPa (0.970 kgf/cm², 14.0 psi)
Front: (Minimum)
76.0 kPa (0.760 kgf/cm², 11.0 psi)
Rear: (Minimum)
90.0 kPa (0.900 kgf/cm², 13.0 psi)
VEHICLE LOAD of 200.0–490.0 kg (441–
1080 lb)
FRONT: (Recommended)
97.0 kPa (0.970 kgf/cm², 14.0 psi)
REAR: (Recommended)
152.0 kPa (1.520 kgf/cm², 22.0 psi)
Front: (Minimum)
90.0 kPa (0.900 kgf/cm², 13.0 psi)
Rear: (Minimum)
145.0 kPa (1.450 kgf/cm², 21.0 psi)
Vehicle load is total weight of operator, pas-
sengers, accessories, cargo, and trailer
tongue weight. Do not exceed maximum
vehicle load of 490.0 kg (1080 lb).
1. Tire tread depth
1
