4-23
E
EJU13590
Specifications
MODEL
ITEM
Unit XLT1200
WATERCRAFT CAPACITY
Maximum people on board Number of people 3
Maximum load capacity kg (lb) 240 (530)
DIMENSIONS
Length mm (in) 3,160 (124)
Width mm (in) 1,220 (48)
Height mm (in) 1,130 (45)
Dry weight kg (lb) 361 (796)
PERFORMANCE
Maximum output kW (PS) @ r/min 114 (153)@ 7,000
Maximum fuel consumption L/h (US gal/h, Imp gal/h) 64 (17, 14)
Cruising range at full throttle hr. 1.09
Trolling speed r/min 1,300–1,400
ENGINE
Engine type 2-stroke
Number of cylinders 3
Engine displacement
cm
3
(cu in)
1,176 (71.8)
Bore & stroke mm (in) 80.0
×
78.0 (3.15
×
3.07)
Compression ratio 5.9:1
Lubrication system Variable oil injection
Cooling system Water cooled
Starting system Electric starter
Ignition system Digital CDI
Spark plug BR8ES-11 (NGK)
Spark plug gap mm (in) 1.0–1.1 (0.039–0.043)
Battery capacity V-AH 12-19
Charging system Flywheel magneto
DRIVE UNIT
Propulsion system Jet pump
Jet pump type Axial flow, single stage
Impeller rotation Counterclockwise (viewed from rear)
Transmission Direct drive from engine
Jet thrust nozzle horizontal angle Degree 24 + 24
Jet thrust nozzle trim angle Degree -10, -5, 0, 5, 10
FUEL AND OIL
Recommended fuel Regular unleaded gasoline
Minimum octane rating PON
RON
86
90
Recommended engine oil YAMALUBE 2-W only
Fuel tank capacity
Total L (US gal, Imp gal) 70 (18.5, 15.4)
Reserve L (US gal, Imp gal) 12 (3.2, 2.6)
Oil tank capacity L (US gal, Imp gal) 5.5 (1.5, 1.2)
UF0V13.book Page 23 Friday, June 6, 2003 11:32 AM
