LOCATION OF IMPORTANT LABELS
1-2
1
TIRE INFORMATION
Cold tire normal pressure should be set
as follows.
• Up to 90 kg (198 lbs) load
FRONT
REAR
: 200 kPa, (2.00 kgf/cm²), 29 psi
: 225 kPa, (2.25 kgf/cm²), 33 psi
• 90kg (198 lbs) ~ maximum load
FRONT
REAR
: 200 kPa, (2.00 kgf/cm²), 29 psi
: 250 kPa, (2.50 kgf/cm²), 36 psi
3B6-21668-00
A1
EMISSION HOSE ROUTING
10D-21686-00
CARB. CARB.
CANISTER
TO ATMOSPHERE
FROM
FUEL TANK
ROLL OVER VALVE
1
2
3
5
4
6 California only
