ENG
4-45
CHECKING THE CLUTCH SPRINGS
The following procedure applies to all of the
clutch springs.
1. Check:
•Clutch spring
Damage → Replace the clutch spring.
2. Measure:
• Clutch spring free length
Out of specification → Replace the clutch
spring.
CHECKING THE CLUTCH HOUSING
1. Check:
• Clutch housing dogs
Damage/pitting/wear → Deburr the clutch
housing dogs or replace the clutch housing.
N
O
TE:N
O
TE:
Pitting on the clutch housing dogs will cause
erratic clutch operation.
CHECKING THE CLUTCH BOSS
1. Check:
• Clutch boss splines
Damage/pitting/wear → Replace the clutch
boss.
N
O
TE:N
O
TE:
Pitting on the clutch boss splines will cause
erratic clutch operation.
CHECKING THE PRESSURE PLATE
1. Check:
• Pressure plate
Cracks/damage → Replace.
Clutch spring free length
47.80 mm (1.88 in)
Minimum length
46.50 mm (1.83 in)
CLUTCH
