Yamind CP101 - Technical Parameters

OXYGEN CONCENTRATOR USER MANUAL
14
TECHNICAL PARAMETERS
Model CP101
Working Voltage
230 V
～
± 10% / 50 Hz ± 1 Hz
Rated Power （VA）
770
Output Pressure=0/7kPa,
the flow range（L/min）
1～10
Output Pressure=0,the
purity value（within 10min，
up to the standard）
Oxygen flow=1～10 L/min，purity≥90%
Highest Flow 10 L/min
Highest Flow with 7kPa
pressure
，
change of flow
≤
1 L/min
Highest Flow, purity
（
within
10min
，
up to the standard
）
≥
90%
Range of adusting flow
0～10L/min adusted continously
Net Weight（Kg）
20.5
Noise dB(A)
≤55
Dimension
（
mm
）
L400 × W300 × H540
Oxygen output pressure 60kPa-80kPa
Yellow low oxygen indicator
light
When 72%≤purity≤82%，the yellow indicator will
shin,contact the supplier, Make sure have the spare
oxygen nearby when use it continously.
Red alarm indicator light
When purity ≤72%，red indicator will alarm，and
dispaly show Lo-o2.It will stop within one minute.Please
turn off at once and choose the spare oxygen , contact
the supplier
