YANGDONG Y4100D - Table of Contents

O P E R AT I O N & M AI N T E N AN C E M AN U A L
4
Contents
Dimensional drawings for configuration and installation of diesel engine…………Ⅰ
Section 1. Diesel engine specification and technical dates
1、specifications of diesel engine … ………………………………………………1-1
2、specification of the main accessories ………………………………………………1-2
3、Main technical data of diesel engines …………………………………………1-5
Section 2. Operation and security requirements of engine
1、Fuel oil 、lube oil and cooling water ……………………………………………2-1
2、Preparation before starting … …………………………………………………………2-1
3、Starting ………………………………………………………………………………2-2
4、Running ……………………………………………………………………………2-2
5、Stopping …………………………………………………………………………2-3
6、Security requirements ……………………………………………………………………2-3
Section 3 Maintenance
1、Routine maintenance ……………………………………………………………………3-1
2、Maintenance after 100 accumulated operating hours ………………………………3-1
3、Maintenance after 500 accumulated operating hours ………………………………3-2
4、Preservation and storage of engine ………………………………………………………3-3
Section 4 Engine adjustment
1、adjustment of valve lash ………………………………………………………………………4-1
2、adjustment of injection timing ………………………………………………………………4-1
3、adjustment of injector …………………………………………………………………………4-2
4、adjustment of lube oil pressure … ……………………………………………………………4-3
5、adjustment of injection pump …………………………………………………………………4-4
6、adjustment of decompression arm lash ……………………………… ……………………4-4
Section 5 Construction of diesel engine
