- 7 -
Ref#
Description
Qty
3
Screw M6x15
34
4
Lock Washer Ø6
34
5
Hex Nut M6
34
11
Screw M8x20
8
12
Lock Washer Ø8
10
13
Hex Nut M8
10
14
Flat Washer Ø16
4
16
R Pin Ø3
4
18
Hex Bolt M8x30
2
20
Spacer
2
22
Latch Spring
1
24
Hitch Pin
1
25
Hex Bolt M6x90
1
26
Lock Nut M6
1
Component Parts
