PARTS LIST

Part # Description Qty Part # Description Qty

1 Carriage Bolt M6x25 1 28 R Pin Ø3 1

2 Tooth Washer Ø8 1 29 Lock Nut M6 18

3 Gauge & Lever Assembly 1 30 Screw M5X12 2

4 Adjust Handle Pole 1 31 Connect plate 2

5 Adjust Handle A 1 32 Bolt M6x55 2

6 Adjust Handle B 1 33 Wheel Frame Assembly (Right) 1

7 Screw M4x18 1 34 Pneumatic Wheel 2

8 Hopper Screen 1 35 Connect Rod 2

9 Spacer 1 36 Inner Hex Bolt M5x45 1

10 Wing Nut M6 1 37 Inner Axle Bushing 2

11 Hopper 1 38 Outer Axle Bushing 2

12 Center Cover 1 39 Gear Box & Axle Assembly 1

13 R Pin Ø2 1 40 Screw M4x20 1

14 Bolt M6x40 4 41 Big Flat Washer Ø6 5

15 Fixed Plate 1 42 Nylon Washer 1

16 Screw Ø5X12 4 43 Line Clamp Press Plate 2

17 Adjustable Plate 1 44 Control Rod 1

18 Wheel Frame Assembly (Left) 1 45 Rain Cover 1

19 Impeller 1 46 Thin Washer 1

20 Line Clamp Bottom Plate 1 47 Big End Cap 1

21 Lock Nut M5 5 48 Small End Cap 2

22 Tube End Cap 5 49 Axle End Cover 2

23 Bolt M6x35 9 50 Flat Washer Ø16 1

24 Round Head Bolt M5x10 2 51 Fixing Connecting Rod 1

25 Round Head Pin 1 52 Spring Washer Ø6 1

26 Tow Bar Connect Plate 2 53 Hex Bolt M6x45 4

27 Install Tube Assembly 1
