STORAgE
When the leaf mulcher is stored at the end of the season, disassemble and stack in the
following order:
1. Place the funnel into the box.
2. Fit the motor housing into the funnel.
3. Place the funnel cover onto the motor housing
4. Rest the legs in the box beside assembly.
Fig.17
TECHNICAL DATA
Rated Voltage: 120 V, 60 Hz
Rated Power: 13 amp
No Load Speed: 8,000/min
Mulch Ratio: 12:1
Max. Cutting Diameter: 12 in. (30.4 cm)
Line Diameter: 0.095 in. (0.25 cm)
Weight: 13.45 lbs (6.1 kg)
