Yard Machines 410 - Page 19

19
Model 420
REF.
NO. PART NO. DESCRIPTION
1 735-0246 Vinyl End Plug
2 647-0014 Clutch Control Ass’y.
3 710-1017 Torx Mach. AB-Tap Scr.
4 786-0131 Handle Cover
5 786-0098 Retaining Brkt.—R.H.
6 786-0118 Retaining Brkt.—L.H.
7 720-0278 Grip (2 Req’d.)
8 720-0210A Knob
9 712-3008 Hex Jam Nut 3/8-16 Thd.
11 735-0127 Rubber Washer
12 736-0204 Fl-Wash. .344" I.D. x .6" O.D.
13 747-0902 Gear Shift Rod
14 714-0104 Hairpin Clip
15 649-0016 Handle Ass’y.
16 710-0896 Tap Scr. 1/4-14 x 5/8" Lg.
17 726-0330 Cable Clip
21 746-0916 Clutch Cable
22 786-0120 Depth Bar
23 736-0117 Fl-Wash. 3/8" I.D. x 5/8" O.D.
24 710-0253 Hex Bolt 3/8-16 x 1" Lg.*
28 715-0120 Spiral Pin 3/16" x 1"
29 686-0095 N Shift Crank Ass’y.
30 711-0415 Clevis Pin
31 714-0149B Hairpin Clip
32 642-0015 Tine Ass’y.—L.H.
642-0016 Tine Ass’y.—R.H. (Not Shown)
33 786-0090 Side Shield
34 786-0113 Rear Tine Shield
35 686-0044A N End Cover Ass’y.
36 738-0849 Hex Screw 5/16-18 x .75" Lg.
38 710-0118 Hex Bolt 5/16-18 x .75" Lg.
39 710-3097 Carriage Bolt 3/8-16 x 1" Lg.
40 712-0798 Hex Nut 3/8-16 Thd.
43 712-3004A Hex Fl. Tp. L-Nut 5/16-18 Thd.
44 786-0076 Tine Shield Brkt.—R.H.
45 786-0077 Tine Shield Brkt.—L.H.
46 711-0415 Clevis Pin .375" Dia.
47 786-0085 Tine Shield
48 747-0432 Tiller Flap Rod
49 726-0106 Cap Speed Nut
50 710-0521 Hex Bolt 3/8-16 x 3" Lg.
51 786-0101A N Shift Cover
52 710-1017 Torx Mach. AB-Tap Scr.
1/4 x .6"
54 686-0071 Handle Positioner Brkt. Ass’y.
55 686-0048 Handle Pivot Brkt. Ass’y.
56 784-0191 Hex Nut Retainer Brkt.
57 712-0379 Hex Flange Nut 3/8-24 Thd.
59 784-0190 Handle Adjustment Crank
60 710-0189 Hex Bolt 5/16-18 x 3" Lg.
61 732-0493 Torsion Spring
62 712-0375 Hex L-Nut 3/8-16 Thd.
63 748-0375 Handle Swing Link
64 736-0317 Bell-Wash. 5/8" I.D.
65 712-0386A Hex Slotted Nut 5/8-18 Thd.
66 714-3021 Cotter Pin 1/8" x 1-5/8"
67 747-0901 Handle Adjustment Rod
68 712-0421 Knob 5/16-18 Thd.
69 736-0169 L-Washer 3/8" I.D.
