IMPORTANT: Do not over bend the support rods during the following step. Over bending will cause the
steel rods to lose supporting tension.
(Figure 16) Tip the hopper onto its back to assemble the two hopper support rods. Place the ends
of each rod into the upper and lower rear hopper tubes bending the rod just enough to fit into the
holes in the tubes.
(Figure 17) Feel along the stitched flap on the hopper bag to locate the lower hole in each upper
hopper side tube. Place a hole through both sides of the stitched flaps in alignment with the lower
hole.
