Yardbird 21833 - Page 13

Operator’s Manual
Chicken Plucker
Check for parts online at www.yardbirdpluckers.com or call 800-345-6007 M-F 8-5
13
ITEM
NO.
PART # DESCRIPTION QTY.
1 23632 HOSE TUB WATER SPRAYER 1
2 24018 ASSY DRUM W/HOSE CLIPS 1
3 22577 FINGER REPLACEMENT 98 MM 95
4 22697 FINGER REPLACEMENT 46 MM 13
5 23646 BUCKLE CLAMP 4
6 23649 FITTING TEE 3/4 NPT X BARB
X BARB
1
7 23924 O-RING 24 X 26 X 3.5 MM 1
8 23844 FITTING 3/4 FNPT X GARDEN
HOSE SWIVEL
1
9 10677 BOLT M6 X 1.0 X 30 HEX 2
10 18130 WASHER M6 SPRING LOCK 10
11 23840 WASHER M8 X 30 DOMED 1
12 24016 KEY SQUARE 6 X 6 X 17.4 1
13 W1265V0904 BOLT M8 X 1.25 X 20 HEX 1
14 23639 FEATHER PLATE 1
15 400023 NUT M8 NYLOCK 16
16 4650 NUT M6 X 1.0 NYLOCK 5
17 24032 BOLT M8 X 1.25 X 45 PHILIPS 4
18 3245 WASHER M8 X 24 X 2.2 FLAT 32
19 24033 BOLT M8 X 1.25 X 20 PHILIPS 2
20 23925 O-RING 26 X 21 X 3 MM 1
21 23636 PLUG SQUARE TUBE 30 MM 6
22 23637 FEATHER CHUTE 1
ITEM
NO.
PART # DESCRIPTION QTY.
23 4692 WASHER M4 FLAT 3
24 22024 WASHER M4 SPRING LOCK 3
25 12419 BOLT M4 X 0.7 X 8 PHILIPS 3
26 23104 AXLE LEG TOP 30 MM 2
27 18098 BOLT M8 X 1.25 X 45 HEX 8
28 21640 WASHER M8 SPRING LOCK 6
29 12770 BOLT M8 X 1.25 X 40 HEX 3
30 23089 SUPPORT LEG TOP 30 MM 1
31* W1265V0903 NUT M10 X 1.5 NYLOCK 2
32* 19905 WASHER M10 X 20 X 2 FLAT 2
33* 11919 WHEEL KIT WITH HARDWARE 1
34 23107 SUPPORT LEG BOTTOM 30 MM 1
35 23110 SUPPORT BRACKET AXLE FEM 1
36 23108 AXLE LEG BOTTOM 30 MM 2
37 23795 ASSY AXLE FEMALE PLUCKER 1
38 23864 ASSY AXLE MALE PLUCKER 1
39 23111 SUPPORT BRACKET AXLE
MALE
1
40 23638 FEATHER PAN 1
41** --- MOTOR ASSEMBLY 1
42 23112 WELDMENT FEATHER PLATE
HUB
1
43 24017 CARABINER PLUCKER 4
* PARTS W1265V0903 AND 19905 INCLUDED IN KIT 11919
**MOTOR ASSEMBLY PARTS LIST LOCATED ON PAGE 14.
