Operator’s Manual
Chicken Plucker
Check for parts online at www.yardbirdpluckers.com or call 800-345-6007 M-F 8-5
4
POWER TYPE 120V SINGLE PHASE
WHEELS INCLUDED YES, 2
HORSEPOWER 1.5
ROTATIONAL SPEED RPM 300
FINGERS 110
CARTON HEIGHT TOP TO BOTTOM INCHES 20.7
CARTON WIDTH SIDE TO SIDE INCHES 21.6
CARTON DEPTH FRONT TO BACK INCHES 21.6
ASSEMBLED HEIGHT TOP TO BOTTOM INCHES 36
ASSEMBLED WIDTH SIDE TO SIDE INCHES 30.6
ASSEMBLED DEPTH FRONT TO BACK INCHES 26.7
VOLTAGE VOLTS 120
WATTAGE WATTS 1100
MINIMUM CIRCUIT RATING AMPS 15
GROSS WEIGHT POUNDS 88
NET WEIGHT POUNDS 83
REMOVABLE TUB YES
DRIVE TYPE GEAR
DRIVE DETAILS HELICAL CUT ALLOY STEEL GEARS
IRRIGATION RING YES
FINISH STAINLESS STEEL AND POWDER COAT
SPECIFICATIONS
HARDWARE FINISH CLEAR ZINC
PRIMARY MATERIAL STAINLESS STEEL
PIECES INCLUDED 1 TUB, 1 FEATHERPLATE, 1 WARRANTY
CARD, 1 SET HARDWARE, 1 DRIVE ASSEMBLY, 3 LEGS,
2 WHEELS, 1 OWNER’S MANUAL, 2 AXLES
WEATHER RESISTANT YES
CORROSION RESISTANT YES
UV RESISTANT YES
ANTIMICROBIAL YES
HEAVY DUTY YES
CORD INCLUDED YES
TUB PROXIMITY SAFETY SWITCH YES
OUTDOOR USE YES
COMMERCIAL USE NO
CORD LENGTH INCHES 72
GFCI YES
ASSEMBLY REQUIRED YES
TOOLS NEEDED FOR ASSEMBLY WRENCHES
PRODUCT WARRANTY ONE YEAR
CSA CERTIFIED YES
~
Leakage Protection
L
1 2 1 2
L
1 2 1 2
ZJ
Toggle Switch
Relay
Magnetic Switch
Start Winding
Run Winding
Capacitor
WIRING DIAGRAM
~
Leakage Protection
L
1 2 1 2
L
E
E
Green
Grounding
1 2 1 2
ZJ
Toggle Switch
Relay
Magnetic Switch
Start Winding
Run Winding
Capacitor
To Next Page
