Yardistry YM12863 - Page 24

24 support@yardistrystructures.com
F2.14
HardwareWood Parts
2 x (2233) Short Sill
1 x (2235) Long Sill
F2.11
Sills
Guide Spacer to sit in grooves of Sills and Posts for proper alignment, then to be removed.
S4
6 x #8 x 3” Wood Screw
Sills
Sills
Sills
F2.15
F2.16
F2.17
(2233)
(2235)
(2233)
(2233) (2235)
(2233)
(2235)
S4
Guide Spacer
6 x
(2249)
(2237)
(2237)
(2249)
(2233)
(2235)
Step 2: End Wall with Gable Vent Assembly
Part 5
Outside View
(1188)
Tight
