25 support@yardistrystructures.com
End wall top rail
End wall top rail
End wall top rail
Wood Parts
1 x (2243) End Wall - Top Rail
Hardware
S11
4 x #8 x 2” Wood Screw
LW1
2 x 1/4” Lock Washer
2 x 1/4 x 3” Hex Bolt
H12
FW1
2 x 1/4” Flat Washer
2 x 1/4” T-Nut
TN1
F2.18
F2.19
F2.20
F2.21
(2243)
(2243)
(2243)
(2243)
H12
LW1
FW1
TN1
S11
Tight
(2249)
(2237)
Step 2: End Wall with Gable Vent Assembly
Part 6
Outside View
Flush
