F2.22
L&R Gable and Center Poly
L&R Gable and Center Poly
L&R Gable and Center Poly
Components
1 x PC Gable Panel Right
1 x PC Gable Panel Left
1 x PC Wall Center Short
F2.23
F2.24
Note: Notches
always at the
bottom right of
each panel from
the outside
Top Tape
Bottom Tape
PC Gable Panel
Left
PC Gable Panel
Right
PC Wall
Center Short
Note: UV
Coating to the
outside of the
frame
Outside View
Outside View
Remove lm from both sides of PC Gable Panel Left,
PC Gable Panel Right and PC Wall Center Short
Top Tape
Bottom Tape
Outside View
Step 2: End Wall with Gable Vent Assembly
Part 7
Refer to pages 17 and 18 and apply top and bottom
tape to PC Gable Panel Left, PC Gable Panel Right
and PC Wall Center Short.
To Next Page
