Yardistry YM12863 - Page 36

36 support@yardistrystructures.com
F3.6
(2244)
Wood Parts
2 x (2233) Short Sill
1 x (2253) Access Sill
Hardware
S4
6 x #8 x 3” Wood Screw
F3.14
F3.15
F3.16
F3.17
(2268)
(1147)
(2249)
(2237)
Guide Spacer
(2253)
(2233)
(2233)
S4
(2233)
(2253)
Guide Spacer
x 6
(2233)
(2253)
Step 3: End Wall Assembly
Part 5
Guide Spacer to sit in grooves of Sills and Posts for proper alignment, then to be removed.
Outside View
(1188)
Tight
