37 support@yardistrystructures.com
Wood Parts
1 x (2243) End Wall - Top Rail
Hardware
S11
4 x #8 x 2” Wood Screw
LW1
2 x 1/4” Lock Washer
2 x 1/4 x 3” Hex Bolt
H12
FW1
2 x 1/4” Flat Washer
2 x 1/4” T-Nut
TN1
F3.18
F3.19
F3.20
S11
(2243)
(2243)
Step 3: End Wall Assembly
Part 6
Outside View
(2237)
End wall top rail
(2243)
H12
LW1
FW1
TN1
(2249)
Flush
F3.21
Flush
(2243)
