F3.23
Components
1 x PC Gable Panel Left
1 x PC Gable Panel Right
Top Tape
Bottom Tape
Remove lm from both sides of PC Gable Panel
Left and PC Gable Panel Right.
Note: UV
Coating to the
outside of the
frame
Note: Notches
always at the
bottom right of
each panel from
the outside
F3.22
Outside View
PC Gable Panel
Left
PC Gable Panel
Right
Step 3: End Wall Assembly
Part 7
Bottom Tape
Top Tape
F3.24
Outside View
Refer to pages 17 and 18 and apply top and bottom
tape to PC Gable Panel Left and PC Gable Panel
Right.
Center opening is left empty
To Next Page
