Step 6: Frame Assembly
Part 4
Components
4 x 40 Degree Roof to Post Bracket
Wood Parts
2 x (2251) Side Wall - Top
Hardware
S11
8 x #8 x 2” Wood Screw
LW1
4 x 1/4” Lock Washer
4 x 1/4 x 3” Hex Bolt
H12
FW1
4 x 1/4” Flat Washer
4 x 1/4” T-Nut
TN1
F6.15
F6.16
F6.17
F6.18
F6.19
Inside View
Outside View
H12
LW1
FW1
TN1
40 Degree Roof to
Post Bracket
40 Degree Roof to
Post Bracket
(2251)
(2251)
(2251)
(2251)
S11
