Step 6: Frame Assembly
Part 3
F7.4
Remove lm from both sides of PC Wall Panel.
Note: Notches
always at the
bottom right of
each panel from
the outside
PC Wall Panel
F6.10
PC Wall Panel
Notch
PC Wall Panel
Side Wall with
Vent Assembly
End Wall
Assembly
End Wall
Assembly
End Wall
Assembly
Side Wall with
Vent Assembly
Side Wall with
Vent Assembly
Side Wall with
Vent Assembly
Components
2 x PC Wall Panel
Top Tape
Bottom Tape
Hardware
4 x #10 x 4” Wood Screw
S24
S24
Side Wall
Assembly
PC Wall Panel
PC Wall Panel
PC Wall Panel
Tight
Flush
F6.11
F6.12
F6.14
F6.13
Top Tape
Bottom Tape
Refer to pages 17 and
18 and apply top and
bottom tape to PC
Wall Panel.
