Part Identification ( )
Dimensions are approximate and are shown to assist in the identification of parts for
assembly. Actual dimensions may be smaller or larger.
4pc. (2234)
Side Wall Sill FSC 681.7 mm (26-7/8")
4pc. (2237)
Corner Post FSC 2038.4 mm (80-1/4")
Y50229-2237
4pc. (2233)
Short Sill FSC 520.8 mm (20-1/2")
Y50229-2236
Y50229-2238
2pc. (2235)
Long Sill FSC 726.3 mm (28-5/8")
Y50229-2235
Y50229-2234
Y50229-2233
1pc. (2236)
Gable End Right Upright FSC 472.3 mm (18-5/8")
2pc. (2238)
Window Trim FSC 1114 mm (43-7/8")
Y50229-2231
2pc. (1137)
Long Shelf Joist FSC 406.4 mm (16")
2pc. (1134)
Shelf Gusset FSC 536.6 mm (21-1/8")
2pc. (1135)
Shelf Joist FSC 381 mm (15")
Y50229-1135
Y50229-1134
4pc. (2231)
Shelf Top FSC 1814.7 mm (71-7/16")
Y50229-1137
Y50229-2230
Y50229-2232
4pc. (2232)
Top Shelf FSC 1681.3 mm (66-9/16")
4pc. (1138)
Wooden Gusset FSC 203.2 mm (8")
Y50229-1130
Y50229-1138
Y50200-1188
1pc. (2230)
Shelf Front FSC 1690.9 mm (66-9/16")
2pc. (1188)
Guide Spacer FSC 262 mm (10-5/16")
2pc. (1130)
Door Block FSC 1935.2 mm (76-3/16")
Y50229-1129
1pc. (1129)
Top Door Block FSC 690 mm (27-3/16")
