Yardline 4130 User Manual

17
FORT
FLOOR FRAME
Flush
3” Screws x16
Flush
16-1/4”
16-1/4”
FORT
FLOOR FRAME
x2
2365-MS
To Center of
2364-MS
x4
2364-MS
5/4 x 4 x 43-1/8”
5/4 x 4 x 71-3/4”
Flat Washer
Lock Washer
3-3/4" Hex Bolt
x4
!IMPORTANT!
Install 2365-MS
counterbores facing
toward inside.
T-Nut x4
47"
CHECK HEIGHT.
