Yardline 4130 - Page 20

18
FORT
FLOOR FRAME
FORT
FLOOR FRAME
1/4”
!IMPORTANT!
Mark L-BRACKET locations at
each corner. Ensure 1/4” distance
between L-BRACKET and lower
edge of frame as shown.
Drill-Through 1/4” marked L-BRACKET locations at
each corner.
Re-Drill through using 1/2” bit from outside of frame at each
L-BRACKET hole location.
x4
2084
SEE PAGE 7
