Yardline 4130 - Page 37

35
FORT
BALUSTERS
S P A C E R
S P A C E R
S P A C E R
S P A C E R
S P A C E R
S P A C E R
S P A C E R
S P A C E R
LEFT SIDE / PICNIC SIDE
Center spacer between posts.
5/8 x 3-1/4 x 34-1/2”
x9
2324-MS
1-1/4” Screws x12
1-1/4"
1-1/4"
STEP LADDER
ASSEMBLE
2-1/2” Wood Screws (x16)
Back side
of ladder
x1
2 x 4 x 51”
2318-MS
x1
2 x 4 x 51”
2319-MS
x4
2 x 4 x 15-3/8”
1051-MS
