TWO PERSON SWING
TWO PERSON SWING
ASSEMBLE
ASSEMBLE
Push Cap
Push Cap
Push Cap
5-7/8” Seat pin
5-7/8” Seat pin
15-5/8” Foot rest pin
5/16” Washer
5/16” Lock Nut
Tighten Lock Nut until 2-3 threads are exposed
and insert pin through foot rest and swing brace.
Tap Push Cap onto rod using hammer and insert
pin through seat and swing brace.
Orient seats to point toward the
center of swing.
LOCK NUTS MUST BE USED FOR ALL
ASSEMBLY OF TWO PERSON SWING!
x2
To Next Page
