Yardline 4130 User Manual

49
TWO PERSON SWING ASSEMBLE
5/16” Washer
Tighten Lock Nut until
2-3 threads are exposed.
Hold foot rest pin by the threads while
tightening lock nut on other side
5/16” Lock Nut
TWO PERSON SWING ASSEMBLE
2388-MS
Push Cap
Using 2388-MS as a brace, tap the top
push cap with a hammer until secure.
x2
1 x 4 x 5-1/2”
