Yardline 4130 User Manual

50
TWO PERSON SWING ASSEMBLE
1” Eye bolt
Coated chain to
eye bolt side.
HOOK CHAIN TO EYE BOLT BEFORE INSTALLING.
1” Eye bolt
1/4” Washer
1/4” Washer
1/4” Lock Nut
1/4” Lock Nut
Ensure Lock Nuts are
tightened enough to
expose 2-3 threads.
TWO PERSON SWING MOUNT ASSEMBLE
2” Carriage bolt
3/8” Lock Nut
x2
3/8” Lock Nut
3/8” Washer
3/8” Washer
END VIEWEND VIEW
Aling brackets with
pre-drilled holes
x2
2 x 4 x 20”
2389-MS
