Yardline RIDGEPOINTE User Manual

8
42"
16"
32-1/4"
48"
64"
72"
80"
96"
108"
120"
72" 48"
(106,7 cm)
(40,6 cm)
(81,9 cm)
(304,8 cm)
(162,6 cm)
(183 cm)
(152,4 cm)
(244 cm)
(274,3 cm)
(304,8 cm)
(183 cm) (121,9 cm)
1-1/2"
(3,8 cm)
48"
(121,9 cm)
1
3" (7,6 cm)
PARTS REQUIRED:
NOTE:

FLOOR FRAME
BEGIN

x40
Center
on marks
Arrange parts as shown on at surface. Measure and mark each dimension from end of boards.
Secure with (2) 3" nails at each mark and (4) nails at seams.
Flush
at ends
HINT:


Flush
at ends
Seam

Nails
Seam
x9
2 x 4 x 42" (5 x 10 x 106,7 cm)
TREATED
x2
2 x 4 x 48" (5 x 10 x 122 cm)
TREATED
x2
2 x 4 x 72" (5 x 10 x 183 cm)
TREATED
