49
1
PARTS REQUIRED:
Install (2) corner sof ts primed side out and ush to trim .
Secure corner sof ts to gable overhang frame with (4) 1-1/4" screws at each side.
x8
1-1/4" (3,2 cm)
FRONT OVERHANG TRIM
Flush
Flush
Screws
Your corner sof ts are now installed.
FINISH
x2
3/8 x 4-1/8 x 8-1/2" (1,0 x 10,5 x 21,6 cm)
Install all trim and soffi t parts with the primed side facing outward.
HINT:
Pre drill to avoid
3/16" (4,8 mm) Drill Bit
To Next Page
