55
Your transom windows are installed.
FINISH
Place window ush to the measured line.
Center the window across the door panel .
Align center of window to center lines.
Seal window with high quality exterior-grade caulk
behind frame before installing window .
Fasten window with (2) 3/4" screws at both sides
and with (4) 3/4" screws across top of window
.
5
4
6
PARTS REQUIRED:
DOOR TRANSOM WINDOWS
BACK SIDE OF LEFT DOOR
(2,9 cm)
Flush window
to line
(2,9 cm)
LEFT DOOR
Screws
You must caulk completely around window
frame and all exposed door panel edges
and trim to validate your warranty.
Use a paintable exterior rated caulk.
At front side of door, apply caulk along bottom edge
of window .
FRONT OF DOOR
For the left door, measure 1-1/8" from bottom of opening
at two locations .
Mark each measurement.
Scribe a line across door panel.
Mark center of window opening at top and bottom.
Caulk between
frame and door.
CENTER
on lines
CENTER CENTER
To Next Page
