4
x4
2 x 3 x 83-13/16" (5,1 x 7,6 x 212,9 cm)
HPP
RAFTERS OVERHANG & TRIM SHELF
LOFT
DOOR
UN
x2
2 x 4 x 94-1/2" (5,1 x 10,2 x 240 cm)
RL
x2
2 x 4 x 24" (5,1 x 10,2 x 61 cm)
PARTS LIST continued...
KP
x2
1 x 4 x 96" (2,5 x 10,2 x 243,2 cm)
JS
x2
1 x 4 x 23-7/8 (2,5 x 10,2 x 60,6 cm)
OO
x2
69" Door Stiffener (175,3 cm)
x12
2 x 3 x 10-1/2" (5,1 x 7,6 x 26,7 cm)
AE
x1
2 x 3 x 10-5/8" (5,1 x 7,6 x 27 cm)
x1
2 x 3 x 20-1/2" (5,1 x 7,6 x 52,1 cm)
WAF
7/16 x 8 x 12-1/2" (1,1 x 20,3 x 31,8 cm)
x12
x2
19/32 x 2-1/2 x 20-5/8" (2,5 x 6,3 x 52,4 cm)
GPA
x6
2 x 3 x 5-1/2" (5,1 x 7,6 x 14 cm)
URB
x2
19/32 x 2-1/2 x 23" (2,5 x 6,3 x 58,4 cm)
GI
x1
19/32 x 2-1/2 x 49-3/16" (1,5 x 6,3 x 124,9 cm)
HNR
x1
19/32 x 2-1/2 x 49-3/16" (1,5 x 6,3 x 124,9 cm)
HNL
PANEL PARTS LIST
ROOF PANELS
SHELVES & LOFT
FLOOR
NOTE: Panel parts are not stamped.
7/16 x 23-7/8 x 96"
(1,1 x 60,6 x 243,8 cm)
x1
7/16 x 11-1/2 x 96"
(1,1 x 29,22 x 243,2 cm)
x2
7/16 x 11-1/2 x 23-7/8"
(1,1 x 29,22 x 60,6 cm)
x2
x11
7-1/4 x 18-1/4" (18,4 x 46,4 cm)
OSB OR WOOD GRAIN
x1
3/8 x 14-5/8 x 43-1/8" (1,0 x 37,1 x 109,5 cm)
19/32 x 2-1/2 x 27-9/16" (1,5 x 6,3 x 70 cm)
BZL
x1
19/32 x 2-1/2 x 27-9/16" (1,5 x 6,3 x 70 cm)
BZR
x1
x2
19/32 x 5-1/2 x 6-5/8" (1,5 x 14 x 16,8 cm)
x2
19/32 x 5-1/2 x 6-5/8" (1,5 x 14 x 16,8 cm)
x12
2 x 4 x 83-13/16" (5,1 x 10,2 x 212,9 cm)
GPN
x2
3/8 x 8-1/2 x 76-5/8" (1 x 21,6 x 194,6 cm)
x2
7-1/4 x 18-1/4" (18,4 x 46,4 cm)
WOOD GRAIN
x2
19/32 x 3-1/2 x 81-1/4" (2,5 x 8,9 x 206,4 cm)
AOL
x2
19/32 x 3-1/2 x 81-1/4" (2,5 x 8,9 x 206,4 cm)
AOR
x2
7/16 x 48 x 96"
(1,1 x 121,9 x 243,2 cm)
x2
7/16 x 36-5/16 x 96"
(1,1 x 92,2 x 243,2 cm)
x2
7/16 x 31,3/4 x 36-5/16"
(1,1 x 80,6 x 92,2 cm)
x2
7/16 x 23-1/4 x 36-5/16"
(1,1 x 59,1 x 92,2 cm)
x2
7/16 x 23-1/4 x 48"
(1,1 x 59,1 x 121,9 cm)
x2
7/16 x 31-3/4 x 48"
(1,1 x 80,6 x 121,9 cm)
5/8 x 48 x 96"
(1,6 x 121,9 x 243,8 cm)
x2
5/8 x 45 x 96"
(1,6 x 114,3 x 243,8 cm)
x1
5/8 x 23-7/8 x 96"
(1,6 x 60,6 x 243,8 cm)
x1
5/8 x 23-7/8 x 45"
(1,6 x 60,6 x 114,3 cm)
x1
