61
(3,8 cm)
Screws
SET
SCREW
Your T-handle and decorative hinges are now installed.
Attach inside handle and secure with set screw.
Install decorative hinges on horizontal trim and ush against hinge, as shown.
2
Insert handle in hole and secure with 1-1/4" screws.
FINISH
1-3/4" (4,4 cm)
35-3/4"
(90 cm)
RIGHT DOOR
1-3/4"
(4,4 cm)
DOOR HARDWARE / DECORATIVE HINGES
x1
3/4" (1,9 cm)
x12
x4
x2
PARTS REQUIRED:
1-1/2" (3,8 cm)
Keep drilled hole square to
trim to avoid breaking edge
of door stiffener.
1
Measure and mark location of hole on outside of right door as shown .
Pre-drill hole with 1/4" drill.
Re-drill hole with 3/8 " drill.
3/8" (10,9 cm) Drill Bit
1/4" (0,6 cm) Drill Bit
Flush
To Next Page
