60
PARTS REQUIRED:
1" (2,5 cm)
x2
x8
5/16" (0,8 cm) Drill Bit
DOOR HARDWARE
Install bolt with screws supplied and drill 5/16" hole for bolt to extend into.
Install bolt with screws supplied and drill 5/16" hole for bolt to extend into.
Place bolt onto OO in open position with bolt end 1/2" up from oor.
Bolt is open when loop is contacting base .
3
4
2
Place spring bolt onto OO in open position with bolt end 3/8" down from frame.
Bolt is open when loop is contacting base .
Mark and pre-drill holes for screws.
Mark and pre-drill holes for screws.
1
LEFT
DOOR
Your spring bolts are now installed.
FLOOR
Loop contacts
base.
x4
x4
Loop contacts
base.
PRE-DRILL
PRE-DRILL
1-1/4 x 2-1/2 x 69"
position.
OO
OO
1-1/4 x 2-1/2 x 69"
FINISH
