Plate Compactors
Operator’s Manual
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE
MODEL NUMBER
YC1160
YC1390
SERIAL NUMBER
PURCHASE DATE
Both model number and serial
number may be found on the
main label (see
Page 2, Figure 1a
& Figure 1b
). You should record
both of them in a safe place for
future use.
