PARTS LIST
26
Power Wheelbarrow
»
Operator’s Manual
YD4103PM02 - 1706
Parts List
|
No. Description
Qty
109 Seal FB17X47X7 1
110 Spring 1
111 Steel Ball 6 1
112 Gearshift Fork Shaft 1
113 Gearshift Fork 1
114 Slip Duplex Pulley 1
115 Ciclip 15 1
116 Rivet Assembly 1
117 Joint Bolt 1
118 Plate 1
119 Expansion Brake Cover 1
120 Bolt M8X30 3
121 Bolt 1
122 Brake Pull Plate 1
123 Brake Disk 2
124 Spring 2
125 Vent-Plug 1
126 Gasket 1
127 Bearing 6302 1
128 Pulley 1
129 Shaft I 1
130 Swing Plate 2
131 Bolt M6x20 2
132 Pulley 1
133 Big Washer 6 4
134 Seal FB16X22X4 2
No. Description
Qty
135 Pin 12x20 2
136 Gear Box Case ( R) 1
137 Clutch Fork Shaft ( R) 1
138 Plug 2
139 Screw M8x25 2
140 Clutch Fork Shaf 2
141 Bearing 6303 5
142 Gear II-5 1
143 Gear II-4 1
144 Gear II-3 1
145 Gear II-2 1
146 Gear III-4 1
147 Gear III-3 1
148 Gear III-2 Bush 1
149 Gear III-2 1
150 Gear Shaft III 1
151 Shaft II 1
152 Key C5x20 2
153 Bush 1 1
154 Bush 2 1
155 Gear II-1 1
156 Output Shaft 2
157 Output Gear Bush Gasket 1
158 Gear Box Case ( L) 1
159 Washer Groupware 14 1
160 Plug M14X1.5 1
No. Description
Qty
161 Clutch Fork Shaft (L) 1
162 Cable Connecting Plate Weldment 1
163 Bolt M8X130 6
164 Output Gear Bush Gasket 2
165 Ciclip 25 2
166 Spring Gasket 4
167 Clutch Bush 2
168 Joint Bush 2
169 Ciclip 26 2
170 Joint Bush Composite Bushing 2
171 Joint Bush 1
172 Output Gear 1
173 Ciclip 58 2
174 Steel Ball 5 42
175 Spring Gasket 2
176 Spring Guidebush 2
177 Clutch Spring 2
178 Gasket 1 4
179 Screw M10x50 2
180 Driving Wheel 2
181 Output Shaft House 2
182 Guard Cover 1
183 Bolt M8X20 10
184 Output Shaft Composite Bushing 4
185 Seal FB42X25X7 2
186 Right Wheel 2
To Next Page
