M10 × 25 × 2
5
M12 × 40 × 2
Figure 3e
7. Install the already assembled plow blade to the trackbarrow
as shown. (See Figure 3e)
M10×25 (×2) M12×40 (×2)
17
mm
18
mm
30
mm
13
mm
11
mm
17
mm
18
mm
30
mm
13
mm
11
mm
10
Power Trackbarrow
»
Operator’s Manual
YD8103PM03 - 1802
