YARDMAX YD8103 User Manual

No. Description Qty
139 Gear II-5 1
140 Gear II-4 1
141 Gear II-3 1
142 Gear II-2 1
143 Gear III-2 Bush 1
144 Gear III-2 1
145 Gear Shaft III 1
146-1 Gear Box Case ( L) 1
147 Plug M14×1.5 2
148 Washer Groupware 14 2
149 Gear Box Case 1
150 Output Shaft 2
151 Gear II-1 1
152 Bush 2 1
153 Bush 1 1
154 Key C5×20 2
155 Spline ShaftII 1
156 Discontinued N/A
157 Clutch Fork Shaft (R) 1
158-1 Gear Box Case ( R) 1
159 Pin 12×20 2
160 Seal FB16×22×4 2
161 Output Shaft Bush Gasket 2
162 Gasket 1 4
163 Clutch Spring 2
164 Spring Guide Bush 2
165 Clutch Sleeve 2
166 Spring Gasket 2
167 Steel Ball 5 70
No. Description Qty
168 Circlip 58 2
169 Output Gear 1
170 Intermediate Joint Bush 1
171
Intermediate Joint Bush
Composite Bushing
2
172 Circlip 26 2
173 Joint Bush 2
174 Spring Gasket 4
175 Circlip 25 2
176 Washer 8 10
177 Output Shaft Bushing 2
178 Seal FB42×25×7 2
179
Output Shaft Composite
Bushing
4
180 Screw M8×25 w/glue 12
181 Guard Cover 1
182 Bolt M8×35 2
183 Plug 35×35 2
184 Sponge Gasket 1
185 Seal Gasket 1
186 Seal Gasket 6 2
187 Screw-Plug M18×1.5 2
188 Brake Pull Plate 1
189 Bolt M10×35 1
190 Shifting Lever I 1
191 Shifting Lever II 1
192 Gear Shifting Board 1
No. Description Qty
110 Gear 1
111 Bearing 6302 1
112 Gearshift Fork Guide Pin 1
113 Spring 1
114 Steel Ball 6 1
115 Gearshift Fork 1
116 Circlip 12 1
117 Rivet Assembly 1
118 Brake Disk 1
119 Discontinued N/A
120 Discontinued N/A
121 Discontinued N/A
122 Washer6 4
123 Washer6 7
124 Bolt M6×16 4
125 Expansion Brake Cover 1
126 Stud 1
127 Vent-Plug Bushing 1
128 Vent-Plug 1
129 Screw M8×30 3
130 Expansion Brake Lock Bolt 3
131 Screw M8×130 6
132 Clutch Fork Shaft (L) 1
133 Bolt M6×20 3
134 Swing Plate 2
135 Gear III-4 1
136 Gear III-3 1
137 Large Belt Pulley 1
138 Bearing 6303 5
24
Power Trackbarrow
»
Operator’s Manual
YD8103PM03 - 1802
Parts List
|
