Yardworks 060-1778-0 User Manual

EXPLODED VIEW
27
Item N
o
. Part No. Description
16
16-1
16-2
16-3
16-4
16-5
16-6
16-7
16-8
16-9
16-10
16-11
16-12
16-13
16-14
16-15
16-16
16-17
3220345 Screw
34104229 Battery housing
Cord (red)
Cord (black)
Battery cover
32201229 Screw
36501229 Connector shell
3660239-1
36502229 Connector terminal
3050245 Cord (blue)
3050145 Cord (Yellow)
3290575 Wire terminal
3419650 Flag terminal bushing
3330550 Flag terminal
36504229 60 A fuse
3650139
34104226-1 PCB cover
3690292 Tape
34105229 Battery handle
Charge socket
33301229 Hook
16-18
16-19
16-20
16-21
16-22
16-23
34103229
3050102
3050110
3030175
3650211
3650239
Diode
Battery terminal
Pyrocondensation tube
Battery 20 AH
24 V 20 Ah battery Assy.
31107229-1
