Yardworks 060-2273-4 User Manual

model no. 060-2273-4 | contact us: 1 866 523 5218 model no. 060-2273-4 | contact us: 1 866 523 5218
To Turn On/Off
1. Press the safety lock out button (2) and squeeze
the trigger switch (1) to start.
2. Release the trigger switch (1) to stop.
Edging function
This trimmer is equipped with an edging feature for
use on the sidewalks or walkways, patios and/or
driveways to clear over-grown grass from manicured surfaces.
1. Pull up edging coupler and turn handle end
counterclockwise.
2. Release edging shaft coupler when handle
has been rotated 180°.
3. Flip the edging guide down until it locks into
place.
1
2
Operation Operation
10 11
PULL UP
BUTTON TO ROTATE
EDGER GUIDE
REAR HANDLE
!
WARNING! To avoid injury:
• Do not squeeze the trigger while the grass
trimmer/edger is inverted.
• Do not carry the grass trimmer/edger with your
Split and telescoping tube
The shaft can be extended or shortened for
ease of use.
1. Unscrew telescoping shaft coupler and
slide to desired position.
2. Tighten telescoping shaft coupler.
The cutting path can be adjust from 10’’ to 12’’.
Phillips screwdriver(not supplied ) will be used.
Loosen the screw and turn the
cutter 180° then tighten the
screw.
This trimmer is equipped with a pivoting head.
1. Please remove the battery from the unit.
2. Using your left hand, grip the nose (1) of the trimmer and use your thumb to depress the
pivoting head adjustment button (2). Using your right hand turn the head to either of the
3 available positions.
3. Now LOCK by releasing the pivoting head adjustment button (2).
10’’
12’’
Adjust the cutting path
Adjust the Cutting Angle
SPLIT AND
TELESCOPING
SHAFT
54°
36°
1
2
3
